Demystifying Hooks

Andrea Giammarchi
10 min readNov 7, 2019

--

Photo by Chunlea Ju on Unsplash

While many could see React Hooks some sort of sorcery, the concept behind is pretty simple, and I’d like to explain in few lines of code how do these work.

In a nutshell …

This is the simplest representation of a hook I can think about:

const hooked = fn => function hook() {
/* setup hook details */
try { return fn.apply(null, arguments); }
finally { /* rollback hook details */ }
};

The hooked constant can now be used to wrap any callback, so that when it’s invoked, the passed callback will have all the necessary details to run any of the provided APIs, such as useState, useRef, and others.

The instrumentation is needed so that the API can eventually re-invoke the hooked function at any point in time, as example via setState(value).

Since the invocation is synchronous, each hook can setup itself as long as it will put back previous details, if any.

The hooked(fn) utility

Let’s see the basic hooked utility in all its details:

let curr = null;
const current = () => curr;
const hooked = fn => {
const stack = [];
return function hook() {
const prev = curr;
const after = [];
let i = 0;
curr = {
hook, arguments,
stack, get index() { return i++; },
after
};
try { return fn.apply(null, arguments); }
finally {
curr = prev;
after.forEach(fn => fn());
}
};
};

Those few lines of code prepare the function execution in a way that any utility could grab the running hook via current() , and use all the carried information with it:

  • the function hook that is running, including its arguments
  • the hook own stack and an incremental index to store values in it
  • a reference to eventually store callbacks to invoke after the hook has run

The stack

It is fundamental to understand that every hooked function needs a stack to memoize all the possible values needed by any provided API.

This also means that all the various APIs, such as useState, useRef, or others, cannot be defined conditionally, as example via ternary operator, as these might mix up with each other with both execution order and assigned values from the stack.

// this is *wrong*
const [value, update] = condition ?
useState(0) :
useRef([0, () => {}]);

Beside forbidden conditional hooks, asynchronous hooks are also a bad idea, as the current running hook, by the time the asynchronous callback is invoked, might be different, or even null.

The useState(value) hook

Let’s see how the hooked utility can help defining this first API:

const useState = value => {
const {hook, arguments, stack, index} = current();
if (stack.length <= index)
stack[index] = value;
return [stack[index], value => {
stack[index] = value;
hook.apply(null, arguments);
}];
};

Each new hooked function will use its own stack while executing. Such stack is needed, so that one function can have multiple useState(value) in its body.

Each entry of the stack will contain the value initially assigned, or its updated value, reassigned when setState(...), the callback returned as second value, is invoked passing the new value … here an example:

const counter = hooked(() => {
const [first, setFirst] = useState(0);
const [second, setSecond] = useState(1);
console.log(first, second);
return {
first: () => setFirst(first + 1),
second: () => setSecond(second + 1)
};
});
const count = counter();
count.first();
count.second();

As you can see in this code-pen we already have a perfectly working useState utility, capable of returning as many different states, and update callbacks, as needed, thanks to the stack.

However, since the callback is re-invoked each time an update occurs, not only the console output will show the sequence 0 1 , 1 1 , and 1 2 , since the current useState invokes the hook per each update, but we could run count.first() and count.second() forever, without ever seeing the new values passed along … and why is that?

What you see is not always what you get…

The returned object points at two callbacks created only the first time the hooked counter is invoked, but any other invoke, through either setFirst(...) or setSecond(...) updates, won’t be able to update the initial reference, and it will create instead a new object that nothing could consume, with two methods nobody can reach or use.

To dig a bit more, in terms of amount of GC operations, hooks create a quite consistent amount of “trash”, either via objects or callbacks, and it’s only thanks to JavaScript raw performance, when it comes to runtime objects creation and GC execution, that we can simply ignore this fact, as performance will never be super optimal but “good enough” anyway.

The useRef(value) hook

To circumvent the fact the returned object is different per each hook invocation, we could define a useRef utility:

const useRef = value => {
const {stack, index} = current();
return index < stack.length ?
stack[index] :
(stack[index] = {current: value});
};

Similarly to useState, the useRef hook uses the stack, so that more than a useRef call can be found in any hooked callback.

The stack entry is a reference object with a current property, pointing at the related value, if any, set the first time only the callback executes.

From that time on, such reference object will always be the same, so that our counter can now look like the this:

const counter = hooked(() => {
const [first, setFirst] = useState(0);
const [second, setSecond] = useState(1);
console.log(first, second);
const {current: count} = useRef({});
count.first = () => setFirst(first + 1);
count.second = () => setSecond(second + 1);
return count;
});

As you can test live in this pen, whenever we invoke count.first() or count.second(), the new values are respectively updated.

But … will the empty {} always be created?

Yes, but as previously mentioned, it will always be easily trashed by the Garbage Collector, or even ignored if the JS engine is smart enough.

Avoiding unnecessary invokes

Any hooked function could use many states updates at once, and yet with the current logic such function will be executed per each singular one.

Using the counter example, we can see undesired logs between two consecutive updates: one for the first value, and one for the second one.

Ideally, when multiple states are updated at once, what we want to read is just the first invoke, with 0 and 1, and the last one, with 1 and 2. We have no interest in reading, or moving the whole logic, to log 1 and 1 between the first update and the second, but there’s no way to tell the hook to ignore such update, as these could also be fully independent, or triggered at distance in different times.

An easy way to avoid undesired hook calls, is to defer all invokes at once, making the update asynchronous, but optimal in terms of performance.

Meet reraf

Born to solve this, and similar, use cases, the reraf utility is capable of rescheduling, either via requestAnimationFrame, where available, falling back to setTimeout, one, two, or hundreds call to the same function, granting that only the last one will be executed.

This is kinda perfect for hooks, so that we can do a bit of refactoring, introducing reraf, and reuse such utility for other APIs too, such as useEffect.

import reraf from 'https://unpkg.com/reraf?module';
const updates = new WeakMap;
const useState = value => {
const {hook, arguments, stack, index} = current();
if (stack.length <= index) {
stack[index] = value;
if (!updates.has(hook))
updates.set(hook, reraf());
}
return [stack[index], value => {
stack[index] = value;
updates.get(hook)(hook, null, arguments);
}];
};

After this change, we can test live in this pen that the console output is indeed 0 and 1, followed asynchronously by 1 and 2.

If we look closer though, we cannot anymore invoke current.first() many times in a row and expect synchronous increments, for the simple reason the method will still point at the first callback until the asynchronous operation happens, …and this is fine, as invoking repeatedly the same setState(value) doesn’t really have many real-world applications, while undesired executions are heavier and for no gain.

The useReducer(reducer, value[, init]) hook

The reducer allows more complex state changes at once already, but it’s still about states, so that we can use the same utility we have already.

const useReducer = (reducer, value, init) => {
const [state, setState] = useState(init ? init(value) : value);
return [state, value => {
setState(reducer(state, value));
}];
};

The useMemo(fn[, guards]) hook

This one is more similar to useRef, but it’s based on a callback to be invoked either the first time, or only when guards conditions would require so.

const useMemo = (fn, guards) => {
const {stack, index} = current();
if (
!guards ||
stack.length <= index ||
guards.some(different, stack[index].values)
)
stack[index] = {current: fn(), values: guards};
return stack[index].current;
};

If either no guards is passed, or one of its values differs from the previous hook invocation, the result of the invocation of the callback is stored in the stack, together with the new guards. The outcome of the invocation will also be returned, and at this point we have everything we need to implement the next utility too.

The useCallback(fn[, guards]) hook

const useCallback = (fn, guards) => useMemo(() => fn, guards);

Well, I don’t think there’s much to say in here, isn’t it? 😉

The useContext(context) hook

Differently from any other utility described so far, the peculiarity of this one is that many hooks can use the same context to react to changes, whenever these occur.

This makes the usage of the stack meaningless, ’cause such stack is associated only to a single hooked function, so we need to create our own stack, adding every hook that is using the shared context.

const hooks = new WeakMap;
const useContext = context => {
const {hook, args} = current();
const stack = hooks.get(context);
const info = {hook, args};
if (!stack.some(update, info))
stack.push(info);
return context.value;
};
function update({hook}) {
return hook === this.hook;
}

That is pretty much it: we check if our stack already contains a specific hook, and if that’s not the case, we add such hook, and its arguments, to the stack.

… but how is the stack populated, and how are hooks notified once the context changes? … and what is the context anyway?

The createContext(value) utility

While in React a context can be represented as a node that provides some value, in this post it’s simply an object with a value, and a provide(newValue) method.

const createContext = value => {
const context = {value, provide};
hooks.set(context, []);
return context;
};
const invoke = ({hook, args}) => { hook.apply(null, args); };function provide(value) {
if (this.value !== value) {
this.value = value;
hooks.get(this).forEach(invoke);
}
}

At this point, it’s clear that passing a non-context value to the previous useContext(context) utility would throw an error, ’cause no stack has been possibly attached to such object, but of course if the context was previously created, the WeakMap will return its stack, and every time context.provide(newValue) is invoked, every hook registered in such stack will be invoked, and the new value returned per each useContext.

The useEffect(fn[, guards]) hook

The last utility of this list is one that triggers the fn after the hook executed, either synchronously, via createLayoutEffect(fn[, guards]), or asynchronously, via reraf.

The logic involved is slightly more convoluted than before:

  • the fn could return a callback to cleanup previous effects
  • the stack details, per each effect, should not be exposed … but …
  • there must be a way to cleanup all effects that were previously scheduled, simulating componentDidUnmount or, in DOM words, a disconnected element from the live tree.

Accordingly, we can use both the usual stack and its index, but also a WeakMap, to associate both a single reraf function, and any cleanup operation, directly to the running hook, so that third parts libraries can drop, or cleanup, all remaining effects at any time.

const effects = new WeakMap;
const stop = () => {};
const createEffect = sync => (effect, guards) => {
const {hook, stack, index, after} = current();
if (index < stack.length) {
const info = stack[index];
const {clean, invoke, update, values} = info;
if (!guards || guards.some(different, values)) {
info.values = guards;
if (clean) {
info.clean = null;
clean();
}
if (sync)
after.push(invoke);
else
update(invoke);
}
}
else {
const invoke = () => { info.clean = effect(); };
if (!effects.has(hook))
effects.set(hook, {stack: [], update: reraf()});
const details = effects.get(hook);
const info = {
clean: null,
invoke,
stop,
update: details.update,
values: guards
};
stack[index] = info;
details.stack.push(info);
if (sync)
after.push(invoke);
else
info.stop = details.update(invoke);
}
};
const useEffect = createEffect(false);
const useLayoutEffect = createEffect(true);

The logic is basically the following one:

  • first time the useEffect is called, we store in the stack some info regarding the effect, such as the function to invoke after, or asynchronously, one able to stop the effect, if not happened already, values to guard against per each invocation, and a clean property to carry eventual returned callback to clean up the effect.
  • every other time, we ensure the previous cleanup is performed, and we reschedule the update, either after the hook executes, or asynchronously.

The dropEffect(hook) utility

The only missing bit, is a function able to cleanup all remaining effects, in case the hook won’t be executed ever again, or its related DOM node has been removed from the tree.

const dropEffect = hook => {
if (effects.has(hook))
effects.get(hook).stack.forEach(info => {
const {clean, stop} = info;
stop();
if (clean) {
info.clean = null;
clean();
}
});
};

The stop() could be a no-op, and if there’s any clean operation left, the related info is also cleaned up, and the callback invoked to execute such cleanup once.

And That’s All Folks 🎉

I’ve tried to cover basically everything augmentor library offers, using also most of its real code, hoping you followed this journey, also understanding how hooks work internally, and how to use related utilities for your project.

Its dependent dom-augmentor also provides all it takes to invoke dropEffect(hook) when some node is removed from the DOM, which is handy for 3rd parts libraries such as neverland, or even heresy (where hoooks are not in yet, but will be soon).

So, you have all the primitives you need to play around or create the next library, with an overhead of less than 1K, which is the current augmentor size.

Enjoy hooks, and feel free to ask me more either here or in twitter 👋

Compatibility

If you are wondering which browser is compatible with augmentor, or the code in this post, the answer is IE11 or greater, once transpiled, or any other engine compatible with ES6/ES2016.

--

--
